Cloudenergy 36V (38.4V) 105Ah LiFePO4 Golf Cart Battery — Iron Shell
Model: GFS36V-105Ah With Charger | Chemistry: LiFePO4 (LFP) | Nominal Voltage: 38.4V | Capacity: 105Ah (~4.03kWh)
3-in-1 kit: Includes 43.8V 20A fast charger, 2.8″ LCD touch monitor (with holder), and 78.74″ mounting strap—quick, secure installation.
- Bluetooth 200A Smart BMS: App monitoring; 200A continuous (~7.68kW), peak 400A/35s & 600A/3s; low-temp charge cut-off; protections for over/under-voltage, over-current, short-circuit, over-temperature.
- Long life: 6000+ cycles @ 80% DOD—far longer than lead-acid; A-grade cells support up to 2C discharge.
- Rugged & safe: High-strength cold-rolled steel iron shell (IP66), fire-/shock-resistant for demanding environments.
- Made for 36V carts: Universal fit; compatible with major golf cart controllers; ideal for golf carts and trolling motors.
Key specs: Size 11.81″D × 20.91″W × 6.97″H; weight 77.2 lb; 12 cells; internal resistance 20 mΩ; terminal M8×16mm (L).
Support: Cloudenergy technical team replies within 24 hours.
Cloudenergy 36V(38.4V) 105Ah LiFePo4 Golf Cart Battery Features
36V (38.4V)105Ah LiFePO4 Golf Cart Battery lron-shell Specifications
| Parameter | Value |
|---|---|
| Nominal Voltage | 38.4V |
| Nominal Capacity | 105Ah |
| Energy | 4032W |
| Standard Charge Voltage | 43.8V |
| Discharge Cut-off Voltage | 30V |
| Standard Charge Current | 50A |
| Max. Charge Current | 100A |
| Max. Constant Discharge Current | 200A |
| Peak Discharge Current | 400A @30s |
| Dimension | 531*300*177 mm 20.91*11.8*7 inch |
| Weight | 35 kg / 77.2lb |
| Cycle Life | 6000+cycles |
| Charge Temperature | 0~60 °C |
| Discharge Temperature | -20~ 60°C |
| Storage Temperature | 10~ 45°C |
CloudEnergy 36V (38.4V) 105Ah LiFePO4 Golf Cart Battery – Iron Shell, Bluetooth BMS, Touch Monitor & Charger
Model: GFS36V-105Ah With Charger | Brand: CloudEnergy | Voltage: 38.4V DC | Capacity: 105Ah | Weight: 77.2 lbs
Dimensions: 11.81″ D x 20.91″ W x 6.97″ H | Battery Type: Lithium Iron Phosphate (LiFePO4)
Key Features:
- 3-in-1 Complete Package: Includes 36V (38.4V) 105Ah LiFePO4 battery, 43.8V 20A fast charger, 2.8-inch LCD touch monitor, and a 78.74-inch mounting strap for simplified and secure installation.
- 200A Smart Bluetooth BMS: Built-in BMS supports 200A continuous discharge (peak 600A), offering advanced protection against overcharging, over-discharging, short circuits, high current, and temperature extremes. Bluetooth app included for real-time monitoring.
- 6000+ Deep Cycles at 80% DOD: Designed to last 10 times longer than lead-acid batteries. With high energy density and long lifespan, this battery significantly reduces total cost of ownership for fleets.
- 2C Discharge & High Power Output: With a 7.68kW output and support for 2C discharge, this battery ensures stable performance under heavy loads, perfect for steep terrain and utility cart use.
- Iron Shell & IP66 Protection: Built with a cold-rolled steel case that is fireproof, shockproof, and water-resistant (IP66 rated), ensuring durability in harsh outdoor and fleet environments.
- Wide Application & Compatibility: Compatible with most 36V golf carts including Club Car, EZGO, and Yamaha. Also ideal for electric vehicles, marine engines, and trolling motors.
B2B Ready: CloudEnergy provides 24/7 support, OEM/ODM customization, and engineering assistance for distributors, rental fleets, system integrators, and commercial buyers worldwide.
CloudEnergy Packaging, Shipping & Service Policy
Why Choose CloudEnergy for Your Lithium Battery Needs?
- Industry-Leading Expertise – Specialized in LiFePO4 battery R&D and manufacturing since [year]
- Quality Assurance – Professional design team and strict quality control processes
- Flexible Customization – OEM/ODM services available with no MOQ requirements
- Advanced Manufacturing – Automated production using industrial-grade LiFePO4 cells
Secure Battery Packaging
All CloudEnergy lithium batteries are protected with military-grade packaging:
- Inner Protection – Custom blister trays secure each 100Ah LiFePO4 battery
- Double-Layer Cartons – Inner carton + UN-certified outer box with 2mm thick walls
- Safety Markings – Outer boxes feature waterproof, fireproof, and anti-crush warnings
- Final Reinforcement – PVC stretch film for moisture and impact resistance
Global Shipping Options
| Order Type | Shipping Method | Transit Time |
|---|---|---|
| Samples (1-2 units) | Express (DHL/FedEx) | 5-7 business days |
| Bulk Orders | Sea Freight (FOB/CIF) | 30-45 days after deposit |
Note: We provide freight forwarding assistance for all international shipments
Custom Battery Services
CloudEnergy supports complete OEM/ODM customization:
- Voltage (12V/24V/48V) and capacity adjustments
- BMS programming for charge/discharge parameters
- Connector types and cable customization
- Branding options (silk printing, laser engraving)
Our Service Commitment
Rapid Response
24-hour reply guarantee for all technical inquiries Priority Support
12-hour resolution timeline for customer claims
Extended Warranty
10-year quality guarantee on all LiFePO4 batteries (12.8V series)
Quality Assurance Process
Every CloudEnergy battery undergoes:
- 100% capacity testing
- BMS functionality verification
- Final inspection before packaging
Frequently Asked Questions (FAQ)
1. Is this battery suitable for commercial golf cart fleets or rental companies?
Yes. This model is built for professional use, offering 6000+ deep cycles, 7.68kW output, and a robust iron shell—ideal for high-frequency operations like rentals, golf resorts, and utility fleets.
2. What is included in the package?
The 3-in-1 package includes the 36V (38.4V) 105Ah battery, a 43.8V 20A fast charger, a 2.8-inch LCD touch screen, and a 78.74-inch mounting strap for efficient, safe installation.
3. Can the battery be monitored remotely?
Yes. The built-in Bluetooth BMS allows you to monitor battery health, SOC (state of charge), voltage, and temperature via a mobile app, making fleet diagnostics and maintenance much easier.
4. Is it compatible with my existing golf cart controller?
Yes. The GFS36V-105Ah battery is universally compatible with most 36V golf cart controllers including Club Car, EZGO, and Yamaha. It can be used in both original equipment and retrofitting projects.
5. What protections are built into the battery?
The smart BMS provides full protection against overcharge, over-discharge, overcurrent, short circuit, and high/low temperature. It also includes a low-temperature charging cutoff for cold weather safety.
6. Can the battery be used in series or parallel for custom systems?
Yes. Multiple batteries can be configured in parallel to expand capacity. CloudEnergy offers support and guidance for system integration tailored to your application needs.
7. Do you offer OEM or private labeling?
Yes. As a factory, CloudEnergy offers complete OEM and ODM customization, including branding, shell design, communication protocols (CAN/RS485), app integration, and packaging customization.
8. What services are available for B2B clients?
We offer 24/7 technical support, bulk pricing, installation guidance, post-sales service, and global shipping. Long-term service agreements and regional distributor partnerships are also available.
