Cloudenergy 48V (51.2V) 280Ah LiFePO4 Golf Cart Battery — Circular Display MOD
The upgraded Cloudenergy 48V (51.2V) 280Ah LiFePO4 Golf Cart Battery delivers exceptional energy capacity, high power output, and advanced smart monitoring. Equipped with a 250A Bluetooth Smart BMS and circular LCD display, this high-performance lithium battery is designed for demanding golf carts, UTVs, and electric utility vehicles requiring long runtime and reliable power.
Model: GFS-48V-280AH With Charger
Chemistry: LiFePO4 (Lithium Iron Phosphate)
Nominal Voltage: 51.2V
Capacity: 280Ah
Energy: 14,336Wh (14.3kWh)
BMS Smart Protection System
- Upgraded 250A Smart Bluetooth BMS provides stable high-current output with improved MOSFET protection and precise cell balancing.
- Real-Time Monitoring through mobile APP and circular display screen to track SOC, voltage, current, and temperature.
- Advanced Safety Protections including overcharge, over-discharge, overcurrent, short circuit, and high/low temperature protection.
- Low Temperature Charging Cut-Off prevents charging below 0°C to protect battery lifespan in cold environments.
High Capacity & High Power Performance
- 14,336Wh Usable Energy ensures long driving range for golf carts and electric utility vehicles.
- 250A Continuous Discharge supports up to 12.8kW load power.
- 3C Discharge Capability with high-performance Grade A LiFePO4 cells for powerful acceleration and hill climbing.
- 6000+ Deep Cycles @ 80% DOD providing over 10x the lifespan of traditional lead-acid batteries.
Durable & Safe Design
- IP67 SPCC Waterproof Housing ensures excellent resistance to water, dust, and vibration.
- Dual M8 Terminals simplify installation and connection for golf carts and electric vehicles.
- A-Grade LiFePO4 Cells deliver high energy density, excellent thermal stability, and consistent voltage output.
Applications
Engineered for 48V power systems, this high-capacity lithium battery is ideal for:
- Golf carts (Club Car, EZGO, Yamaha)
- Electric utility vehicles and UTVs
- Trolling motors and marine applications
- Light EV conversions
- Renewable energy and auxiliary power systems
Support: Cloudenergy provides 24-hour technical support and professional service for distributors, dealers, and B2B partners worldwide.
Cloudenergy 48V (51.2V)280Ah LiFePo4 Golf Cart Battery Features
Cloudenergy 48V(51.2V)280Ah LiFePo4 Golf Cart Battery Specifications
| Parameter | Value |
|---|---|
| Nominal Voltage | 51.2V |
| Nominal Capacity | 280Ah |
| Energy | 14,336Wh (14.3kWh) |
| Standard Charge Voltage | 58.4V |
| Discharge Cut-off Voltage | 40V |
| Standard Charge Current | 50A |
| Max. Charge Current | 100A |
| Max. Continuous Discharge Current | 250A |
| Peak Discharge Current | 500A @30s |
| Dimension | 821 × 285.5 ×258.1 mm (32.32 × 11.24 × 10.16 in) |
| Weight | 100kg / 220.46 lb |
| Cycle Life | 6000+ cycles |
| Charge Temperature | 0 ~ 60°C |
| Discharge Temperature | -20 ~ 60°C |
| Storage Temperature | 10 ~ 45°C |
Cloudenergy 48V (51.2V) 280Ah LiFePO4 Golf Cart Battery — Circular Display MOD with 250A Bluetooth Smart BMS
Model: GFA48V-280AH With Charger | Brand: Cloudenergy | Voltage: 51.2V DC | Capacity: 280Ah (~14.33kWh) | Cell Type: Lithium Iron Phosphate (LiFePO4)BMS Smart Protection Highlights:
- Upgraded 250A Smart Bluetooth BMS: Advanced MOSFET protection, faster data refresh rate, and high-precision cell balancing ensure stable high-current output and extended battery lifespan.
- Real-Time Monitoring: Monitor battery performance via Bluetooth mobile APP or the built-in circular LCD display, including SOC, voltage, current, temperature, and system status.
- Low-Temperature Charging Protection: Automatic charging cut-off below 0°C protects battery cells and ensures long-term reliability in cold environments.
4-in-1 Complete Kit:
- High-performance 58.4V 20A Li-Ion fast charger
- Circular LCD battery monitoring display
- Charger extension cable for flexible installation
- 78.74” heavy-duty mounting strap for secure battery installation
Key Features:
- 14.3kWh High Energy Capacity: Massive 280Ah capacity provides extended driving range and longer operating time for golf carts and electric utility vehicles.
- High Power Output: Supports 250A continuous discharge (≈12.8kW load power) with powerful acceleration and high torque performance.
- 6000+ Deep Cycles @ 80% DOD: Delivers more than 10× the lifespan of traditional lead-acid batteries, greatly reducing maintenance and replacement costs.
- Rugged IP67 ABS Housing: Waterproof, fireproof, and shock-resistant design ensures reliable performance in demanding environments.
- Dual M8 Terminals: Simplifies wiring and allows flexible series or parallel configurations for scalable power systems.
- A-Grade LiFePO4 Cells: Provides stable voltage output, high safety standards, and superior thermal stability.
Applications:
Engineered for 48V power systems, this high-capacity lithium battery is ideal for:- Golf carts (Club Car, EZGO, Yamaha and other 48V systems)
- Trolling motors and marine auxiliary power
- UTVs, light EVs, and electric utility vehicles
- Off-road vehicles and industrial electric equipment
- Renewable energy storage and backup power systems
Support & Service:
Cloudenergy provides 24-hour customer service and professional technical support. OEM/ODM customization and global dealer partnerships are available for distributors, fleet operators, and B2B energy storage projects.CloudEnergy Packaging, Shipping & Service Policy
Why Choose CloudEnergy for Your Lithium Battery Needs?
- Industry-Leading Expertise – Specialized in LiFePO4 battery R&D and manufacturing since [year]
- Quality Assurance – Professional design team and strict quality control processes
- Flexible Customization – OEM/ODM services available with no MOQ requirements
- Advanced Manufacturing – Automated production using industrial-grade LiFePO4 cells
Secure Battery Packaging
All CloudEnergy lithium batteries are protected with military-grade packaging:
- Inner Protection – Custom blister trays secure each 100Ah LiFePO4 battery
- Double-Layer Cartons – Inner carton + UN-certified outer box with 2mm thick walls
- Safety Markings – Outer boxes feature waterproof, fireproof, and anti-crush warnings
- Final Reinforcement – PVC stretch film for moisture and impact resistance
Global Shipping Options
| Order Type | Shipping Method | Transit Time |
|---|---|---|
| Samples (1-2 units) | Express (DHL/FedEx) | 5-7 business days |
| Bulk Orders | Sea Freight (FOB/CIF) | 30-45 days after deposit |
Note: We provide freight forwarding assistance for all international shipments
Custom Battery Services
CloudEnergy supports complete OEM/ODM customization:
- Voltage (12V/24V/48V) and capacity adjustments
- BMS programming for charge/discharge parameters
- Connector types and cable customization
- Branding options (silk printing, laser engraving)
Our Service Commitment
Rapid Response
24-hour reply guarantee for all technical inquiries Priority Support
12-hour resolution timeline for customer claims
Extended Warranty
10-year quality guarantee on all LiFePO4 batteries (12.8V series)
Quality Assurance Process
Every CloudEnergy battery undergoes:
- 100% capacity testing
- BMS functionality verification
- Final inspection before packaging
