Cloudenergy 48V (51.2V) 120Ah LiFePO4 Golf Cart Battery — Circular Display MOD
The upgraded Cloudenergy 48V (51.2V) 120Ah LiFePO4 Golf Cart Battery is engineered for powerful output, longer runtime, and intelligent battery management. Equipped with a 250A Bluetooth Smart BMS and circular LCD display, this advanced lithium battery is an ideal replacement for lead-acid systems in golf carts, utility vehicles, marine systems, and off-grid power applications.
Model: GFA48V-120AH With Charger
Chemistry: LiFePO4 (Lithium Iron Phosphate)
Nominal Voltage: 51.2V
Capacity: 120Ah
Energy: 6144Wh (6.14kWh)
Dimensions: 531 × 300 × 177 mm (20.9 × 11.8 × 6.97 in)
Weight: 44kg / 97lb
BMS Smart Protection System
- Upgraded 250A Smart Bluetooth BMS delivers stable high-current output with enhanced MOSFET protection and precise voltage balancing.
- Real-Time Monitoring via Bluetooth mobile APP and circular LCD display to track SOC, voltage, current, and battery temperature.
- Advanced Safety Protection against overcharge, over-discharge, overcurrent, short circuit, overheating, and other battery risks.
- Wide Operating Temperature Range from -20°C to 60°C for reliable performance in outdoor and demanding environments.
High Capacity & High Power Performance
- 6144Wh Usable Energy provides extended range and reliable power for 48V golf carts and electric utility vehicles.
- 250A Max Continuous Discharge supports up to 12,800W max load power for strong acceleration and hill-climbing ability.
- 3C Discharge Capability with premium Grade A LiFePO4 cells for higher output and better driving performance.
- 6000+ Deep Cycles delivers over 10× the service life of traditional lead-acid batteries while reducing maintenance costs.
Durable & Safe Design
- Rugged SPCC Metal Housing offers excellent protection against vibration, impact, and harsh field conditions.
- Compact & Lightweight Design makes installation easier than bulky lead-acid battery packs while delivering more usable energy.
- A-Grade LiFePO4 Cells ensure stable voltage, enhanced thermal safety, and reliable long-term performance.
Applications
Engineered for 48V power systems, this high-performance lithium battery is ideal for:
- Golf carts (Club Car, EZGO, Yamaha)
- Electric utility carts and low-speed vehicles
- Trolling motors and marine systems
- Off-grid solar and backup power systems
- Light EV and custom electric vehicle conversions
Support: Cloudenergy provides 24-hour technical support and responsive customer service for distributors, dealers, OEM/ODM projects, and B2B partners worldwide.
Cloudenergy 48V(51.2V)120Ah iron shell LiFePo4 Golf Cart Battery Specifications
| Parameter | Value |
|---|---|
| Nominal Voltage | 51.2V |
| Nominal Capacity | 120Ah |
| Energy | 6144Wh (6.14kWh) |
| Standard Charge Voltage | 58.4V |
| Discharge Cut-off Voltage | 40V |
| Standard Charge Current | 50A |
| Max. Charge Current | 100A |
| Max. Constant Discharge Current | 250A |
| Peak Discharge Current | 400A @35S / 600A @3S |
| Dimension | 531 × 300 × 177 mm (20.9 × 11.8 × 6.97 inch) |
| Weight | 44kg / 97lb |
| Cycle Life | 6000+ cycles |
| Charge Temperature | 0~60 °C |
| Discharge Temperature | -20~ 60°C |
| Storage Temperature | 10~ 45°C |
Cloudenergy 48V (51.2V) 120Ah LiFePO4 Golf Cart Battery — Circular Display MOD with 250A Bluetooth Smart BMS
Model: GFA48V-120AH With Charger | Brand: Cloudenergy | Voltage: 51.2V DC | Capacity: 120Ah (~6.14kWh / 6144Wh) | Cell Type: Lithium Iron Phosphate (LiFePO4)BMS Smart Protection Highlights:
- Upgraded 250A Smart Bluetooth BMS: Advanced MOSFET protection, faster data refresh rate, and high-precision cell balancing ensure stable high-current output and extended battery lifespan.
- Real-Time Monitoring: Monitor battery performance via Bluetooth mobile APP or the built-in circular LCD display, including SOC, voltage, current, temperature, and system status.
- Low-Temperature Charging Protection: Automatic charging cut-off below 0°C protects battery cells and ensures long-term reliability in cold environments.
4-in-1 Complete Kit:
- High-performance 58.4V 20A Li-Ion fast charger
- Circular LCD battery monitoring display
- Charger extension cable for flexible installation
- 78.74” heavy-duty mounting strap for secure battery installation
Key Features:
- 6.14kWh High Energy Capacity: 120Ah capacity provides extended driving range and longer operating time for golf carts and electric utility vehicles.
- High Power Output: Supports 250A continuous discharge (≈12.8kW load power) with strong acceleration and reliable high-load performance.
- 6000+ Deep Cycles @ 80% DOD: Delivers more than 10× the lifespan of traditional lead-acid batteries, greatly reducing maintenance and replacement costs.
- Rugged ABS Housing: Waterproof, fireproof, and shock-resistant design ensures reliable performance in demanding environments.
- Dual M8 Terminals: Simplifies wiring and allows flexible series or parallel configurations for scalable power systems.
- A-Grade LiFePO4 Cells: Provides stable voltage output, high safety standards, and superior thermal stability.
Applications:
Engineered for 48V power systems, this lithium battery is ideal for:- Golf carts (Club Car, EZGO, Yamaha and other 48V systems)
- Trolling motors and marine auxiliary power
- UTVs, light EVs, and electric utility vehicles
- Off-road vehicles and industrial electric equipment
- Renewable energy storage and backup power systems
Support & Service:
Cloudenergy provides 24-hour customer service and professional technical support. OEM/ODM customization and global dealer partnerships are available for distributors, fleet operators, and B2B energy storage projects.CloudEnergy Packaging, Shipping & Service Policy
Why Choose CloudEnergy for Your Lithium Battery Needs?
- Industry-Leading Expertise – Specialized in LiFePO4 battery R&D and manufacturing since [year]
- Quality Assurance – Professional design team and strict quality control processes
- Flexible Customization – OEM/ODM services available with no MOQ requirements
- Advanced Manufacturing – Automated production using industrial-grade LiFePO4 cells
Secure Battery Packaging
All CloudEnergy lithium batteries are protected with military-grade packaging:
- Inner Protection – Custom blister trays secure each 100Ah LiFePO4 battery
- Double-Layer Cartons – Inner carton + UN-certified outer box with 2mm thick walls
- Safety Markings – Outer boxes feature waterproof, fireproof, and anti-crush warnings
- Final Reinforcement – PVC stretch film for moisture and impact resistance
Global Shipping Options
| Order Type | Shipping Method | Transit Time |
|---|---|---|
| Samples (1-2 units) | Express (DHL/FedEx) | 5-7 business days |
| Bulk Orders | Sea Freight (FOB/CIF) | 30-45 days after deposit |
Note: We provide freight forwarding assistance for all international shipments
Custom Battery Services
CloudEnergy supports complete OEM/ODM customization:
- Voltage (12V/24V/48V) and capacity adjustments
- BMS programming for charge/discharge parameters
- Connector types and cable customization
- Branding options (silk printing, laser engraving)
Our Service Commitment
Rapid Response
24-hour reply guarantee for all technical inquiries Priority Support
12-hour resolution timeline for customer claims
Extended Warranty
10-year quality guarantee on all LiFePO4 batteries (12.8V series)
Quality Assurance Process
Every CloudEnergy battery undergoes:
- 100% capacity testing
- BMS functionality verification
- Final inspection before packaging
Frequently Asked Questions (FAQ)
1. Is this 48V 120Ah battery suitable for commercial fleet or rental use?
Yes. With a 120Ah capacity (6144Wh / 6.14kWh), 6000+ cycle lifespan, and 250A continuous discharge capability, this battery is ideal for golf cart fleets, resorts, rental companies, and electric utility vehicles that require reliable daily performance and reduced maintenance.2. What is included in the 4-in-1 package?
The complete kit includes: one 48V (51.2V) 120Ah LiFePO4 battery, a 58.4V 20A fast charger, a circular LCD battery monitoring display, a charger extension cable, and a heavy-duty mounting strap for easy and secure installation.3. Can the battery be monitored remotely?
Yes. The upgraded Bluetooth-enabled 250A Smart BMS allows real-time monitoring of battery voltage, SOC (State of Charge), temperature, current, and cycle count through a mobile app or the built-in circular display.4. Is it compatible with all 48V golf carts?
Yes. This battery supports most mainstream 48V golf cart systems including Club Car, EZGO, and Yamaha models. It can also power trolling motors, electric boats, UTVs, and other 48V electric vehicle platforms.5. What safety protections are built into the battery?
The intelligent BMS includes protection against overcharge, over-discharge, overcurrent, short circuit, and extreme temperatures. It also features a low-temperature charging cut-off to prevent charging damage in cold environments.6. What is the main advantage of the 120Ah capacity?
The 120Ah capacity provides up to 6144Wh (6.14kWh) of usable energy, offering strong driving range, stable power output, and longer operating time compared with standard lead-acid batteries. It is an excellent balance of performance, size, and weight for 48V golf cart systems.7. Can multiple batteries be connected together?
Yes. The dual M8 terminals allow batteries to be connected in parallel to expand capacity for larger power systems. Cloudenergy engineers can assist B2B clients with custom system integration.8. Do you offer OEM or ODM customization for bulk buyers?
Yes. As a lithium battery manufacturer, Cloudenergy provides OEM and ODM services including custom branding, casing design, Bluetooth APP customization, communication protocols (CAN/RS485), and tailored packaging for distributors.9. What after-sales support is available for commercial partners?
Cloudenergy provides 24/7 global technical support, product training, installation guidance, and logistics assistance. Long-term cooperation programs and dealer partnerships are available for distributors and B2B customers.48V 120Ah Iron Shell LiFePO4 Golf Cart Battery with 6144Wh Energy
The CloudEnergy 48V (51.2V) 120Ah iron shell LiFePO4 golf cart battery delivers 6144Wh of usable energy, 250A continuous discharge, and up to 12800W load power. Its durable metal case design provides stronger structural protection for golf carts, LSVs, and electric utility vehicles.
3C Discharge Grade A LiFePO4 Cells
Built with Grade A LiFePO4 cells, this iron shell lithium battery provides stable voltage output, strong 3C discharge performance, and reliable high-current power for acceleration, hill climbing, and daily golf cart operation.
Built-In 250A Smart BMS for Full Protection
The integrated 250A Smart BMS protects the battery from overcharging, over-discharging, overcurrent, overheating, and short circuits. Combined with a rugged iron shell structure, it helps ensure safer and more stable performance in demanding golf cart applications.
Low-Temperature Cut-Off Protection
The smart low-temperature protection system helps prevent charging and discharging damage in cold environments. This feature improves battery safety, protects cell health, and supports reliable performance during winter use.
Real-Time Battery Status Monitoring
Monitor battery performance through the Bluetooth mobile app and circular LCD display. Users can check SOC, voltage, current, temperature, and system status in real time for easier battery management and diagnostics.
Durable Iron Shell for Smoother and Safer Golf Cart Performance
Designed as a heavy-duty lithium upgrade for 48V golf carts, this iron shell battery provides stronger casing protection, stable power output, reduced maintenance, and smoother acceleration compared with traditional lead-acid battery systems.
Compare CloudEnergy Golf Cart Lithium Batteries

|
|
|
|
| Parameter | 48V 120Ah Compact Cube Design Current Model | 48V 120Ah Long Case Design | 48V 120Ah Square Metal Case Design |
| Nominal Voltage | 51.2V | 51.2V | 51.2V |
| Nominal Capacity | 120Ah | 120Ah | 120Ah |
| Energy | 6144Wh / 6.14kWh | 6144Wh / 6.14kWh | 6144Wh / 6.14kWh |
| Battery Case | Iron Shell | ABS Shell | Iron Shell |
| Max. Continuous Discharge Current | 250A | 250A | 250A |
| Max. Load Power | 12800W | 12800W | 12800W |
| Cell Type | Grade A LiFePO4 Cells | Grade A LiFePO4 Cells | Grade A LiFePO4 Cells |
| Cycle Life | 6000+ cycles | 6000+ cycles | 6000+ cycles |
| Operation Temperature Range | -20°C ~ 60°C | -20°C ~ 60°C | -20°C ~ 60°C |
| Dimensions | 326 × 295 × 323 mm 12.8 × 11.6 × 12.7 in | 547 × 288 × 203 mm 21.54 × 11.34 × 7.99 in | 531 × 300 × 177 mm 20.9 × 11.8 × 6.97 in |
| Weight | 44kg / 97lb | 40kg / 88.18lb | 44kg / 97lb |
| Low Temp Cutoff | Yes | Yes | Yes |
| Auto Heated | No | No | No |
| Bluetooth App Support | Yes | Yes | Yes |
| Recommended Use | Golf carts, LSVs, compact utility carts | Golf carts, trolling motors, light EVs | Golf carts, LSVs, utility carts |
